PP-9135W
Product Introduction
01
FEC ANDROID
FEC provides a complete series of Android POS. From 10" to 22" in for lightweight usage, wall-mount as digital display or with stand for different types of POS terminals.
02
SIMPLE ANDROID PANEL PC
A refined Android Panel PC allows various application s and can be adapted to different installatid
03
2nd Display
Dock the second display on the system or connect on the Stand for a larger monitor.
ANDROID
ㆍCPU : RK-3568 Quad-core Cortex-A55
ㆍMemory : 4GB DDR4 on Board
ㆍStorage : 64GB Built-in eMMC
FEC PLATFORM
Multiple software service in one platform. Nubis as
device monitoring supports image/ app OTA.
Specifications
CPU
- Rockchip RK-3568 Quad-core Cortex-A55 up to 2.0GHz
Memory
- DDR4 4GB On Board
Storage
- 64GB Built-in eMMC
Speaker
- 2 x 2W Internal Speaker
Display
- 15.6" TFT, 1920 x 1080
Touch
- True-Flat PCAP
Brightness
- 300 nits
MTBF
- 30K Hours
Power
- 20V/90W External Adaptor
OS
- Android 12
- GMS available
Mounting
- VESA 100 x 100
Certification
- CE / FCC Class B
Appearance
- Plastic + Aluminum + Metal
- Galaxy Grey with Black
Temperature
- Operation: 0°C~ 40°C
- (32°F ~ 104°F)
- Storage: -20°C ~ 60°C
- (-4°F ~ 130°F)
Dimensions (W x H x D)
- •Product: 369 x 236 x 34 mm
- •Carton: 468 x 448 x 156 mm
Weight
- Net 3.17 kg
- Gross 5.19 kg
Port
- 1 x 20V DC Input
- 1x RJ45 Gigabit LAN
- 1x Video Port
- 1x RJ11 Cash Drawer (12V or24V)
- 1 x SD/TF Card Slot (Max: 64GB)
- 1x Recovery button
- 2 x USB 2.0 Type A , 1 x USB 3.0 Type A (OTG)
- 2x RJ45 (COM1, COM2) RS232 (RI/5V/12V)
- Side I/O Interface:
- 1 x USB 2.0
